High-concentration Strong sodium hypochlorite plant system has many derivatives, the main products are chlorine and sodium hydroxide, which can be derived to produce HCl, NaOH, NaClO, NaClO2, NaClO3 and other basic chemicals and pharmaceutical intermediates.The high-concentration 5% 8% 10% 12% 13% 15% sodium hypochlorite generator
Economic Indicators
Salt consumption: 1.9kg/ Kg.Cl2
Electricity consumption: 2.8kw.H / Kg.Cl2
Raw material
| Input | salt, water, electricity |
| Output product | Sodium Hypochlorite |
| Concentration | 5%-15% |
| electrolyzer | membrane electrolysis cell |
MODEL & SPECIFICATION
| Model | Chlorine (kg/h) |
NaCLO Qty 10%(kg/h) |
Salt Consumption (kg/h) |
DC power consumption (kW.h) |
Area Occupy (m2) |
Weight (t) |
| BSHH-100 | 0.5 | 5 | 0.9 | 1.15 | 15 | 0.5 |
| BSHH-200 | 1 | 10 | 1.8 | 2.3 | 20 | 0.8 |
| BSHH-1000 | 5 | 50 | 9 | 11.5 | 100 | 5 |
| BSHH-1600 | 7.5 | 75 | 13.5 | 17.25 | 200 | 6 |
| BSHH-2200 | 10 | 100 | 18 | 23 | 200 | 8 |
| BSHH-3200 | 15 | 150 | 27 | 34.5 | 200 | 10 |
| BSHH-4200 | 20 | 200 | 36 | 46 | 350 | 12 |
| BSHH-6300 | 30 | 300 | 54 | 69 | 500 | 15 |
NOTE: Making special design for those capacity are over 30kg/hr.
Applications
BSHH model provide a safe, efficient and reliable system that enables manufacturers, distributors and consumers of 5%,10%,15% sodium hypochlorite chlorine-containing disinfectants and household chemicals to cost-effectively produce high quality do-it-yourself sodium hypochlorite (bleach), or chemicals such as hydrochloric acid and caustic soda for their own internal use on site, or for distribution and sale.
| Chlor-alkali | Chlorine, sodium hydroxide,sodium hypochlorite preparation |
| Daily chemical | Household bleach and other related preparations |
| Electricity | Circulating water treatment |
| Medicine | Pharmaceutical intermediates |
| Municipal | Water purification plant |
| Sewage treatment plant |
If you want to know more, please contact us.
